Productivity up to 700-1000 kg/hour, depending on the raw material

Pallet shredding productivity up to 25 pieces/hour

Axle diameter: 210 mm, length: 1440 mm

Pallets, wooden pallets, wood logs, branches, forestry waste, wood recycling, wood waste

Number of shredder blades on the rotor: 47 pieces

Standard sieve: 12 mm

Size of shredded output material: 15 - 25 mm, depending on the sieve

Main shredder motor: 37/45 kW

Conveyor motor, wood chip transport belt: 5 - 7.5 kW

Length of wood chip transport belt: 6 meters

Reducer motor, automatic magnetic separation belt: 2.2 - 3 kW

Length of automatic magnetic separation belt: 1 - 1.5 meters

Three-phase current - 400V, coil voltage 24V/230V within +/- 5% limits, frequency 50 Hz

Total installed power: 45-50 kW

Type of raw material: wood logs, pallets, branches, forestry waste, etc.

Technology used since 2022

Length: 1990 mm, Width: 2410 mm, Height: 2480 mm

Weight: 3450 kg

- Shredder

- V1 Chip evacuation screw + Tubular Magnetic Separator + Chip Fan + Ducting and Cyclone

- V2 Wood chip transport belt (L-type) and Automatic magnetic separator - steel object removal

- Control panel and electric control, inverter, panel heating resistor, 10-meter three-phase cable

Hydraulic motor, Soft Starter, Frequency Converter, Automation

Internet connection, Remote control - errors, optional settings

Operating principle: Pallet and wood log shredding - Stage I: crushing, Stage II: The wood chip transport belt separates steel objects using a magnetic separator and transports the wood chips to the sawdust hammer mill. Stage III: The wood chips can be further processed with the sawdust hammer mill model RM-71.45/55.
