Mechanical briquetting press, briquettes from rapeseed-straw or sawdust, 60 mm, "BriqTech" Series, model: BT-050-200. The press operates on a mechanical system with piston drive, pressing the raw material without adhesives or binders, forming briquettes (solid fuel) with a density of up to 1450 kg/m3.
Technical specifications of the briquetting press:
Productivity up to: 250 kg/hour depending on the raw material.
Briquette diameter: 60 mm
Briquette length: 100-300 mm
Main motor power: 18.5 kW
Feeding motor: 1X2.2 kW
Power supply motor: 1X1.5 kW
Total installed power: 23 kW
Three-phase current: 400V, coil voltage 24V/230V within +/- 5% limits, frequency 50 Hz
Length: 2875 mm, Width: 1000 mm, Height: 1200-1800 mm
Weight of the briquetting machine: 1500-1800 kg
Raw material moisture content: 10-12-14-16-18%
Raw material size: 3-8 mm
Briquette density at the outlet of the mechanical briquetting press: up to 1100-1450 kg/m3
Type of raw material: wood sawdust, cereal straw, alfalfa, rapeseed, soy, sunflower husks, corn stalks, walnut shell sawdust, and other biomass residues containing lignin.
Technology used since 2022
Rapeseed briquette press consists of:
Mechanical briquetting press for straw or sawdust, model BT-050-200
7-meter briquette cooling line
Dry raw material homogenization bunker with a volume of 1.6 m3
Raw material transport screw from the bunker to the mechanical briquetting press
Electric control panel and command, inverter, with a 6-meter three-phase cable
Optional accessories for briquetting press - briquette machine:
Dust extractor (for raw material) under the briquette forming head
Consumables set (bushing, piston, conical bushing) model 2023 - special steel, each raw material has a different set
Bunker (silo) for homogenization of dry raw material with overload level sensor, for a 3 m3 briquetting press
Automated briquette length cutter
Semi-automated briquette wrapping in shrink film through a tunnel
