Overview
Pellet Production Line 250 - 400 Kg/Hour Flat Die is designed for biomass pellet production, offering efficiency and reliability in operation.
Pelleting line from vegetable waste:
Complete pellet line from rapeseed-straw, up to 250 or 400 kg/hour
Rotary flat die press 8mm - GFD-0.2 or GFD-0.4
Raw material homogenization hopper - Volume 2-3 cubic meters
Aerodynamic straw dryer DAD-0.4-0.8 moisture up to 35% - 9kW
Straw shredder H-119/3SN
Raw materials: straw, rapeseed, alfalfa, sunflower husks, etc.
Electric consumption is 50% of the total installed power of the line used in operation.
24-month warranty from the commissioning of the pelleting line
Services: Automation of biomass pellet production line, Spare parts, Training
Accessories: Rollers, Roller sleeves, Flat die 295 or 350 mm, Moistening, Real-time moisture display, Steam generator, Hopper overload sensor, Bagging and packaging
Reactive energy compensation panel with capacitor banks in 6 steps, high energy efficiency, cos φ 0,99.
The grounding of the equipment or the complete pelleting line must be carried out in accordance with the provisions of the regulations and technical standards for electrical safety in force.
The grounding system must be sized and checked to ensure a dispersion resistance in accordance with the requirements of applicable regulations (e.g., I7/2011, SR EN 60204-1), guaranteeing personnel protection and safe operation of the equipment.
Conclusion
Pellet Production Line 250 - 400 Kg/Hour Flat Die represents a practical solution for utilizing biomass into ecological fuel, with optimized yield and costs.
