Tiger Wood Pallet Chipper - Wood Log Series
Technical Specifications:
Productivity: up to 1500-2500 kg/hour depending on the raw material
Pallet chipping productivity: up to 60 pallets/hour
Rotor diameter: 360 mm, length: 1400 mm
Pallets, wooden pallets, wood logs, branches, forest residues, wood recycling, wood waste
Number of rotor knives: 108
Number of fixed knives: 6 plates
Standard sieve size: 12 mm
Output size of chipped material: 15-25 mm, depending on the sieve
Main chipper motor power: 55 kW
Conveyor motor power for wood chip transport: 5-7.5 kW
Length of wood chip transport conveyor: 6 meters
Magnetic separator motor power: 2.2-3 kW
Length of automatic separation magnet conveyor: 1-1.5 meters
Three-phase current - 400V, coil voltage 24V/230V within +/- 5% limits, frequency 50 Hz
Total installed power: 65-75 kW
Type of raw material: wood logs, pallets, branches, forest residues, etc.
Technology used since 2022
Length: 2400 mm, Width: 2000 mm, Height: 2250 mm
Weight: 3800 kg
Tiger Wood Pallet Chipper - Wood Log Series consists of:
- Chipper
- Wood chip transport conveyor
- Magnetic conveyor - removes steel objects
- Electric control panel, inverter, heating resistance for control panel, 10-meter three-phase cable
Optional Accessories for Tiger Wood Pallet Chipper - Wood Log Series:
Hydraulic motor, Soft Starter, Frequency Converter, Automation
Internet connection, Remote control - errors, optional settings
Tiger Wood Pallet Chipper - Wood Log Series is specifically designed for use in wood chip and sawdust briquette and pellet production lines or other forest residues.
Operating principle: Wood pallet chipper I stage: crushing, II stage: Wood chip transport conveyor separates steel objects using a magnet and transports the chips to the wood hammer mill. III stage: Wood chips can be further reduced with wood hammer mills RM-71.45/55 or RM-71.45/55.2 models.
