Bale Shredding Complex CGS-1
Bale Shredding Complex CGS-1
Free
Bale Shredding Complex for rapeseed-straw bales Series "BriqTech" model: CGS-1
Maximum bale diameter: 1.8 meters
Productivity up to: 600-1500 kg/hour
Manufactured in the Czech Republic by Briquetting Technology series "BriqTech" and "PellTech" ® - Assembled in the EU and Ukraine
Over 10 years of experience, 24 months warranty
Bale Shredding Complex CGS-1 + Hammer Mill Model: H-119/7SN
Technical specifications:
Productivity up to 600-1500 kg/hour depending on the raw material
Maximum bale diameter for straw bales: 1.8 meters
Cylindrical, rectangular straw bales
Bale density up to 120 kg/m³
Maximum raw material moisture: 25%
Number of straw shredder blades: 361 pieces
Number of hammer mill blades: 14 pieces
Number of hammer mill hammers: 60 pieces
Size of shredded output material: 3 mm - 10 mm, depending on the sieve
Main shredder motor: 30 kW
Conveyor motor, feed belt motor: 2 - 3 kW
Forced output screw motor for shredded material: 1.1-1.5 kW
Main hammer mill motor: 45 kW
Three-phase current - 400V, coil voltage 24V/230V within +/- 5% limits, frequency 50 Hz
Total installed power - 70-80 kW
Raw material type: wheat straw, alfalfa, rapeseed straw, soybean straw, etc.
Technology used since 2022
Length: 7000mm, Width: 2060mm, Height: 2055mm
Weight: 2500 kg

The Bale Shredding Complex CGS-1 consists of:
- Bale Shredder CGS-1
- Hammer Mill Model: H-119/7SN
- Control panel, electrical control, inverter, 10-meter three-phase cable

Optional accessories for Bale Shredding Complex CGS-1:
Soft Starter, Frequency Converter, Automation
Bag Filter
Overload Sensor for bunker/silo with acoustic and visual alarm
Max Bunker Overload Sensors with automated stop and start
The Bale Shredding Complex CGS-1 is designed for use in straw briquette and pellet production lines or other vegetable waste.
Operating principle: CGS-1 Bale Shredder Stage I: crushing cylindrical and rectangular straw bales, Stage II: fine grinding (hammer mill) Model: H-119/7SN, grinds the raw material into 3-10 mm particles. The final fraction is fully prepared for further production of briquettes and pellets or as feed and bedding for animals.
Bale Shredder CGS-1 with Straw Hammer Mill

Our experience in selling complete pelletizing lines and biomass briquette production equipment started in 2010 when we acquired a straw briquette manufacturing line from the manufacturer "Briquetting Technology". This line has a production capacity of 2,500 tons of briquettes per year, making us a straw briquette producer. Throughout our activity, we have become the exclusive dealer of "Briquetting Technology" series PellTech and BriqTech in Europe. We have successfully implemented over 130 projects, including complete biomass briquetting lines, straw briquetting lines, and wood pelletizing lines. Read more...
