Mini pellet press from "PellTech" Series, model: GFD-0.8 with Rotary Flat Die
Technical specifications:
Pellet production capacity: up to 1000-1400 kg/hour depending on the raw material and die hole diameter
Optional Feed Granules production capacity: up to 1000-2800 kg/hour depending on the raw material and die hole diameter
Flat die diameter: 400 mm
Pressing roller diameter: 185 mm
Pellet diameter: 6-8-10 mm
Adjustable pellet length: 15-30 mm
Main motor: 2 X 45 kW
Total installed power: 115 kW
Three-phase current - 400V, coil voltage 24V/230V within +/- 5% limits, frequency 50 Hz
Dimensions: 7500 X 2500 X 3000 X 2
Weight: 2 X 3500 kg
Raw material moisture content: 12-14-16% - moisture affects pellet quality and productivity
Raw material size: 3-5 mm
Pellet density at the pellet press outlet: up to 1250 kg/m3
Bulk density in Big-Bags: up to 700 kg/m3
Raw material types: wood sawdust*(particle size 3-5 mm, 70% hardwood and 30% softwood, optional 1.0-1.5% dextrin, steam generator), cereal straw, grains, rapeseed, alfalfa, feed, and other biomass residues.
Each raw material has different tapering and dimensions for the rotary flat die
The patented gear unit from Briquetting Technology, "PellTech" series, provides reliability, performance, and stable operation 24/24. The gear unit in the pellet press with Timken bearings and Shell oil is designed for operation under extreme conditions. The gear unit's operation is tested and approved by Timken®.
Technology used from 2023
Mini pellet press - Pellet production press line consists of:
-Raw material hopper with screw feeder
-Mini component feeding screw (lignin, dextrin, bran, etc.)
-Mixing screw with raw material humidification system
-Automated oil lubrication system for the pellet press
-Oil cooling radiator with a fan
-Pellet press
-Rotary flat die with 4 fixed rollers*(pneumatic grease every 2/4 hours, without production stoppage, Timken bearings, Total Ceran XM460 grease)
-Vibrating sieve
-Dust extraction system
-Pellet conveyor belt with dust extraction
-Control panel and electrical control, inverter, Eaton soft starter, with 10-meter three-phase cable
The mini pellet press from "PellTech" Series, model: GFD-0.8, is used industrially in biomass pellet production lines*(pellet production lines) or separately.
Kit for converting the pellet press into a feed granulator
Steam generator
Raw material humidification system
Hopper (Silo) for homogenization with a volume of 3-5 cubic meters controlled by a frequency converter-driven screw
Pellet cooler with a volume of 3 cubic meters + Pellet conveyor belt
Automated roller greasing system
Rollers, Flat dies with 6-8-10 mm holes
Frequency converter
Semiautomatic or automated bagging in bags or Big-Bag
Baler for straw bales CGS-1, CGS-2
Branch crusher RK-2.1
Aerodynamic dryer for straw or sawdust DAD-0.6-1.2
Mechanical briquetting press from "BriqTech" Series BT-070-800, BT-070-800Max
