Biomass Pelletizing Line

Production Line for Pellets 1000 - 1600 kg/hour with Flat Die
Production Line for Pellets 1000 - 1600 kg/hour with Flat DieProduction Line for Pellets 1000 - 1600 kg/hour with Flat DieProduction Line for Pellets 1000 - 1600 kg/hour with Flat DieProduction Line for Pellets 1000 - 1600 kg/hour with Flat Die
Production Line for Pellets 1000 - 1600 kg/hour with Flat Die
Free

Pelletizing Line, Pellet Production Line up to 1000-1600 kg/hour
Raw Materials: Straw, Rapeseed, Alfalfa, Sawdust, Sunflower Husks
Pellet Diameter: 6-8 mm
Over 10 years of experience Warranty: 12 months

Pelletizing Line for Vegetable Residues:
Complete pellet production line for rapeseed straw-hay, sawdust up to 1000-1600 kg/hour, pellet size 6-8mm
Mini Complex Pellet Press - Rotating Flat Die Pellet Press 6-8mm - GFD-0.8
Raw material homogenization bunker - Volume 3-5 cubic meters
Hay Aerodynamic Dryer DAD-0.6-1.2 or DAD-0.6-1.2Max, humidity up to 35% - 25-30kW
Sawdust Rotary Dryer SPB10 or SPB-20, humidity up to 35-45% - 44kW
Bale Shredding Complex for rectangular or round bales CGS-2 or Branch Shredding Complex RK-2.1 or Flat Vibrating Screen CVP-2
Raw materials: straw, sawdust, sunflower husks, etc.
Electric consumption is 50% of the total installed power of the operational line
12-month warranty from the start of the pelletizing line operation
Services: Biomass pellet production line automation, Spare parts, Training
Accessories: 400mm ring or flat pellet die, Moisturizing system, Moisture display in the flow, Steam generator, Bunker overload sensor, Pellet bagging

Our experience in selling complete pelletizing lines and biomass briquette production equipment started in 2010 when we acquired a straw briquette manufacturing line from the manufacturer "Briquetting Technology". This line has a production capacity of 2,500 tons of briquettes per year, making us a straw briquette producer. Throughout our activity, we have become the exclusive dealer of "Briquetting Technology" series PellTech and BriqTech in Europe. We have successfully implemented over 130 projects, including complete biomass briquetting lines, straw briquetting lines, and wood pelletizing lines. Read more...
